NOMINAL SIZE:
DN50 - DN400

BODY TYPE:
WAFER type with through holes
LUG type with threaded holes

WORKING PRESSURE:
6 bar / 10 bar

FLANGE CONNECTION: :
PN6 / PN10 / PN16 / Class 150

WORKING TEMPERATURE:
-40 °C / +200 °C

WORKING MEDIA:
Purified industrial water, Potable water, Industrial cleaners, Chemicals, Food, Beverages, Aggressive liquids, Toxic and Caustic media, Paper mill, Pharmaceutical, Chlorine, Alkalines, Acid, Dyes

TIGHTNESS:
Class A

BODY MATERIAL:
Ductile iron 0.7043 (GGG40.3)
Stainless steel  A351Gr CF8M (only on request)
